element object
diagram girr_ns_p72.png
namespace http://www.w3.org/1999/xhtml
properties
content complex
mixed true
children param p h1 h2 h3 h4 h5 h6 div ul ol dl pre hr blockquote address fieldset table form a br span bdo map object img tt i b big small em strong dfn code q samp kbd var cite abbr acronym sub sup input select textarea label button noscript ins del script
used by
groups head.misc special
attributes
Name  Type  Use  Default  Fixed  annotation
idxs:ID
classxs:NMTOKENS
styleStyleSheet
titleText
langLanguageCode
lang
documentation
<div>
<h3>lang (as an attribute name)</h3>
<p>
       denotes an attribute whose value
       is a language code for the natural language of the content of
       any element; its value is inherited.  This name is reserved
       by virtue of its definition in the XML specification.</p>
</div>
<div>
<h4>Notes</h4>
<p>
      Attempting to install the relevant ISO 2- and 3-letter
      codes as the enumerated possible values is probably never
      going to be a realistic possibility.
     </p>
<p>
      See BCP 47 at <a href="http://www.rfc-editor.org/rfc/bcp/bcp47.txt">
       http://www.rfc-editor.org/rfc/bcp/bcp47.txt</a>
      and the IANA language subtag registry at
      <a href="http://www.iana.org/assignments/language-subtag-registry">
       http://www.iana.org/assignments/language-subtag-registry</a>
      for further information.
     </p>
<p>
      The union allows for the 'un-declaration' of xml:lang with
      the empty string.
     </p>
</div>
dirderived by: xs:token
onclickScript
ondblclickScript
onmousedownScript
onmouseupScript
onmouseoverScript
onmousemoveScript
onmouseoutScript
onkeypressScript
onkeydownScript
onkeyupScript
declarederived by: xs:token
classidURI
codebaseURI
dataURI
typeContentType
codetypeContentType
archiveUriList
standbyText
heightLength
widthLength
usemapURI
namexs:NMTOKEN
tabindextabindexNumber
source <xs:element name="object">
  <xs:complexType mixed="true">
    <xs:choice minOccurs="0" maxOccurs="unbounded">
      <xs:element ref="param"/>
      <xs:group ref="block"/>
      <xs:element ref="form"/>
      <xs:group ref="inline"/>
      <xs:group ref="misc"/>
    </xs:choice>
    <xs:attributeGroup ref="attrs"/>
    <xs:attribute name="declare">
      <xs:simpleType>
        <xs:restriction base="xs:token">
          <xs:enumeration value="declare"/>
        </xs:restriction>
      </xs:simpleType>
    </xs:attribute>
    <xs:attribute name="classid" type="URI"/>
    <xs:attribute name="codebase" type="URI"/>
    <xs:attribute name="data" type="URI"/>
    <xs:attribute name="type" type="ContentType"/>
    <xs:attribute name="codetype" type="ContentType"/>
    <xs:attribute name="archive" type="UriList"/>
    <xs:attribute name="standby" type="Text"/>
    <xs:attribute name="height" type="Length"/>
    <xs:attribute name="width" type="Length"/>
    <xs:attribute name="usemap" type="URI"/>
    <xs:attribute name="name" type="xs:NMTOKEN"/>
    <xs:attribute name="tabindex" type="tabindexNumber"/>
  </xs:complexType>
</xs:element>

attribute object/@declare
type restriction of xs:token
properties
isRef 0
facets
Kind Value annotation
enumeration declare
source <xs:attribute name="declare">
  <xs:simpleType>
    <xs:restriction base="xs:token">
      <xs:enumeration value="declare"/>
    </xs:restriction>
  </xs:simpleType>
</xs:attribute>

attribute object/@classid
type URI
properties
isRef 0
source <xs:attribute name="classid" type="URI"/>

attribute object/@codebase
type URI
properties
isRef 0
source <xs:attribute name="codebase" type="URI"/>

attribute object/@data
type URI
properties
isRef 0
source <xs:attribute name="data" type="URI"/>

attribute object/@type
type ContentType
properties
isRef 0
source <xs:attribute name="type" type="ContentType"/>

attribute object/@codetype
type ContentType
properties
isRef 0
source <xs:attribute name="codetype" type="ContentType"/>

attribute object/@archive
type UriList
properties
isRef 0
source <xs:attribute name="archive" type="UriList"/>

attribute object/@standby
type Text
properties
isRef 0
source <xs:attribute name="standby" type="Text"/>

attribute object/@height
type Length
properties
isRef 0
facets
Kind Value annotation
pattern [-+]?(\d+|\d+(\.\d+)?%)
source <xs:attribute name="height" type="Length"/>

attribute object/@width
type Length
properties
isRef 0
facets
Kind Value annotation
pattern [-+]?(\d+|\d+(\.\d+)?%)
source <xs:attribute name="width" type="Length"/>

attribute object/@usemap
type URI
properties
isRef 0
source <xs:attribute name="usemap" type="URI"/>

attribute object/@name
type xs:NMTOKEN
properties
isRef 0
source <xs:attribute name="name" type="xs:NMTOKEN"/>

attribute object/@tabindex
type tabindexNumber
properties
isRef 0
facets
Kind Value annotation
minInclusive 0
maxInclusive 32767
pattern [0-9]+
source <xs:attribute name="tabindex" type="tabindexNumber"/>


XML Schema documentation generated by XMLSpy Schema Editor http://www.altova.com/xmlspy
